copy of Art.407 Valvola a sfera F.F.F. 3 vie a "L" PN40
413
| Codice | Misura | DN | W | C | D | E | F | gr | Inner | Master |
|---|---|---|---|---|---|---|---|---|---|---|
| 413/01 | 1/4" | 10 | 26 | 54 | 82,5 | 91,5 | 14 | 380 | 10 | 10 |
| 413/02 | 3/8" | 10 | 26 | 54 | 82 | 92 | 14 | 346 | 15 | 15 |
| 413/03 | 1/2" | 15 | 26 | 55 | 82,5 | 92 | 14 | 302 | 15 | 15 |
| 413/04 | 3/4" | 20 | 31.5 | 66 | 88,5 | 92 | 16,5 | 438 | 5 | 5 |
| 413/05 | 1" | 25 | 38.5 | 75 | 96,5 | 114,5 | 16,5 | 635 | 8 | 48 |
| 413/06 | 1.1/4" | 32 | 47 | 85 | 119,5 | 149 | 18 | 1010 | 2 | 2 |
| 413/07 | 1.1/2" | 40 | 54 | 97 | 131,5 | 149,5 | 19,5 | 1574 | 4 | 4 |
| 413/08 | 2" | 48 | 67 | 109 | 149,5 | 149 | 21 | 2379 | 2 | 2 |
| 413/09 | 3" | 80 | 100 | 179 | 253 | 241 | 30 | 7342 | 1 | 1 |
