| Codice | Misura | DN | PN | C | D | W | E | gr | Inner | Master |
|---|---|---|---|---|---|---|---|---|---|---|
| 2415/01 | 1/4" | 11,6 | 63 | 49 | 48 | 18,5 | 96 | 180 | 20 | 80 |
| 2415/02 | 3/8" | 12,5 | 63 | 48 | 47,5 | 20,5 | 95,5 | 178 | 20 | 80 |
| 2415/03 | 1/2" | 15 | 63 | 85 | 53,5 | 26 | 105 | 280 | 15 | 60 |
| 2415/04 | 3/4" | 20 | 63 | 65 | 62 | 30,5 | 113,5 | 396 | 10 | 40 |
| 2415/05 | 1" | 25 | 63 | 77 | 63 | 37 | 128,5 | 553 | 6 | 24 |
| 2415/06 | 1.1/4" | 32 | 63 | 91 | 81 | 45,5 | 162 | 1029 | 1 | 20 |
| 2415/07 | 1.1/2" | 38 | 63 | 99 | 84 | 52,5 | 158 | 1340 | 1 | 15 |
| 2415/08 | 2" | 50 | 63 | 121 | 103 | 65 | 196 | 2007 | 1 | 7 |
| 2415/09 | 2.1/2" | 64 | 63 | 145 | 128 | 82,5 | 250 | 4198 | 1 | 4 |
| 2415/10 | 3" | 76 | 63 | 165 | 135 | 97,5 | 248,5 | 5830 | 1 | 2 |
| 2415/11 | 4" | 94 | 63 | 198 | 163,5 | 119,5 | 303 | 8468 | 1 | 2 |
